Supports over 100 RFID card types in standard package with varies optional RFID modules that cover up to over 10 extra advanced secured RFID protocols, which almost cover most of the end-user requests, enabling high flexibility for multi-card types.
The Armatura design team is dedicated to ensuring the Explorer Series reaches the highest security expectations.
Complies with AES128 encryption standards between PC (USB2.0) and reader communication. Secured Data Storage: Certified EAL6+ encryption chips to enhance data protection performance to the finical grading security level.
Ability to work in both indoor & outdoor environments. Resistant to UV degradation. UL94V-0 standard ensures burning combustion is not sustained for more than 10 seconds after applying controlled flame.
Advanced-Data protection using crypto chips with EAL6+ certified. AES128 end-to-end encryption between the Armatura One server and client side, ensuring all communications are secure.
UL94V-0 standards for flammability ensures burning combustion is not sustained for more than 10 seconds after applying a controlled flame.
Supports 125 kHz, 13.56 MHz and 2.4GHz frequency credentials. Supports 100+ card types, covering most of the common card formats in the market.
Specifications |
|
| Internal Number | EP20ENC |
| Operating Frequency / Standards | 125 kHz 13.56 MHz: ISO14443A types A & B, ISO15693 |
| Functions | RFID Reading |
| Communications & PC Connection | OSDP (v2.2) via USB2.0 (Up to 128bits SCP Secure Communication) |
| Reading Distance | 13.56MHz & 125kHz: Up to 5.1"/130 mm (depending on environment and transponder) |
| Data Protection | AES128 (Secured Communication between Reader & PC) Secure Data Storage in EAL 6+ Certified Crypto Chip |
| Visual Indicator | RGB LEDs |
| Audio Indicator | Internal buzzer |
| Power Requirement / Power Supply | 5 VDC Power supply through the USB port - 1.5 m / 3.28 ft USB cable |
| Operating Temperature | -40°F - 149°F /-40°C to 65°C |
| Dimensions | 3.52" W x 4.23" H x 0.90" D (89.5 x 107.5 x 23mm) |
| Certifications | CE, FCC, RoHs3.0, WEEE(Coming Soon)UL294(Coming Soon) |
| Mounting | Desktop |
| UV Stability | Nil structural degradation for the life of the reader in 3 years |
| Housing Material | Polycarbonate UL94-V0 & UL746C (F1) Housing |
| Compatible Operating Systems | Windows® 7, Windows® 10 & Windows® 11 |
