ProFace X a fully upgraded version of the ProFace product line, which is designed to deal with all kinds of scenarios. It’s powered by the latest ZKTeco-customized CPU for running the intellectualized engineering facial recognition algorithm to boost up the performance in all aspects.
With its powerful core and the latest facial recognition algorithm, the ProFace X facial recognition capability has reached a new height in the biometrics industry with a maximum of 100,000 facial templates, facial recognition speed less than 0.3 sec per face, ultimate anti-spoof ability against almost all types of fake photos and videos attack.
Other than the powerful core, ProFace X is also equipped with the latest face capture system, which enables the terminal to recognize faces under extreme strong light conditions (50,000 lux), and a microwave detector to precisely evaluate the distance between the user and the device for waking up the terminal.
ProFace X comes with a robust design that can work in extreme weather conditions from -30°C to 60°C (-22°F to 140°F) ; The IP68 dust and waterproof standard and IK04 protection standard also enhance its outdoor durability.
ProFaceX supports video intercom via the mobile App ZSmart. Also, the ProFace X integrates with the ONVIF video protocol to connect to the ONVIF NVR for video surveillance and recording. Moreover, ProFace X supports SIP Protocol connect to the indoor unit.
| Face Capacity | 30,000 (1:N) ; 100,000 (Optional) |
| Palm | 5,000 (Customized) |
| Users / Card Capacity | 50,000 |
| Transaction Capacity | 1,000,000 (Optional 2,000,000) |
| User Photo Capacity | 30,000 |
| Event Photo Capacity | 10,000 |
| Compatibility | Security Relay Box Wiegand / RS485 Slave Reader with FP / RFID / Barcode / QR-code Software: ZKBio CVSecurity Mobile App: ZSmart (Optional) |
| Hardware | 1GHz Dual Core Customized Computer Vision CPU 1G RAM / 8G Flash 8" (400lux) IPS Touch LCD 125KHz EM Reader / 13.56MHz MF (Optional) 2MP WDR Low Light Camera Adjustable Light brightness LED Hi-Fi Voice Microphone Distance Detection Sensor Reset Button and Tamper Switch |
| Access Control Interface | Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensorr |
| Special Function | IP68 & IK04 0.3s High Speed Face Verification Live Face detection Communication Https Encrypted Optional Event Snapshot Video intercom ONVIF Protocol (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A) SIP ProtocoI (Compatible with VT07-B01,Optional) |
| Standard Function | Access Levels, Groups, Holidays, DST, Duress Mode (Password), Anti-Passback, Record Query, Custom Wallpaper & Screen Saver, Tamper Switch Alarm |
| Communication | TCP / IP / Wiegand Input / Output / Wi-Fi (Optional) / RS485* / RS232* |
| Additional Info | |
| Algorithm | ZKFace 3.9 & ArmaturaPalm(Customized) |
| Operating Temperature | -30°C ~ 60°C (-22°F~ 140°F) |
| Operating Humidity | ≤ 93% |
| Storage Temperature | -40°C ~ +65°C |
| Storage Humidity | ≤ 93% |
| Net Weight | 853 g |
| Dimension | 227 * 143 * 26 mm (L*W*D) |
| Power | |
| Operating Voltage | 12V DC |
| Current Draw | < 2,000 mA |
